Sapphire Scientific Apex 570 Truck Mount

SKU SAP-72570
In stock
Product Details

To Learn about Our Special Truck Mount Package Deals and Discounts

Call : (800) 711-4716


Request a quote

Sapphire Scientific Apex 570 Truck Mount , More Consistent Heat , Even Longer Life

This duel wand unit sets the new standard for longevity and reliability in a liquid-cooled power plant. NEW Cerakote ceramic coating on all Apex 570 exhaust components lowers the exhaust temperature inside your van. That minimizes heat-related issues and promises a longer life for your truckmount!

Powered by a liquid-cooled cast iron 31 HP Kubota engine, this truckmount uses the patented Sapphire Scientific triple-source thermal well system to deliver consistent high heat. Cerakote ceramic coating lowers the heat radiation on all exhaust components by more than 30%—extends truckmount life and helps to keep van interiors cooler, reducing maintenance and keeping you on the job making money


  • Duel Wand Capable
  • Console with removable shrouds
  • Waste tank with automatic shut-off
  • 150 ft. - 2" vacuum hose with connectors
  • 150 ft. - 1/4" I.D. high pressure solution hose w/ quick connect
  • 50 ft. - water supply hose w/ quick connect
  • 14" Low Profile 6-jet titanium wand (67-081) with glide (67-084)
  • 5 gallon chemical jug and holder
  • Group 24 battery box (battery not included)
  • Operation and service manual
  • Vehicle-specific fuel installation kits sold separately
  • All units include Legend Reward points. End customer must establish a rewards account and register their machine for warranty online to receive points.

Power plant: Kubota WG972 31 HP liquid cooled cast iron gasoline engine operating at 3000 RPM
Vacuum pump: Gardner Denver trilobe HeliFlow® HF408 helical positive displacement blower. Vacuum at 13 in. and flows up to 455 CFM.
Solution pump: General HTS2016S producing up to 1500 PSI and 5 GPM at 1500 RPM
Waste tank: 90 gal. marine grade aluminum. Optional: 120 gal. high capacity waste tank
Belt cooling: 100 CFM through-frame air injection system
Dimensions: Console (W × H × D): 22 × 43 × 50 in. | 56 × 109 × 127 cm
Frame construction: 0.125 in. × 2 in. powder-coated aluminum box tubing.
